2019 Baoma DB703A Startgatvonker
Verkocht
2019 Baoma DB703A Startgatvonker
€17.500 (EUR)
Specificaties
| Fabrikant | Baoma DB703A |
| Model | Startgatvonker |
| Jaar | 2019 |
| Conditie | Gebruikt |
| Https | //www.bmedm.com/drill-edm/959.html |
| Status | Te koop |
| Artikelnummer | Ri |
| Item | DB703A |
| Worktable size(l×w)mm | 436×316 |
| Table travel(x×y)mm | 400×300 |
| Z axis travel mm | 270+(300) |
| Max. drilling depth mm | 0-270 |
| Max. drilling speed mm2/min | 60 |
| Max re-track speed of spindle mm/min | 320 |
| Max. working current a | 30 |
| Electrode diameter | 0.3-3.0 |
| Load of table kg | 300 |
| Working solution | Water/Saponification |
| Working reservoir capacity l | 25 |
| Power supply | 380V AC/50 Hz or 415V AC/50 Hz |
| Max. power consumption kva | 3.5 |
| Machine dimension mm | 1060×750mm×1700 |
| Package dimension mm | 1300×1040×2030 |
| Machine weight kg | 600 |
| Controller type | Automatic Z axis |
| Digital display | X,Y,Z axis |
| Function of setting depth | yes |
| Function of group drilling | yes |
